AIM EVO4S Data logger

€1 699,20
Price incl. VAT (19%) €271,30
In stock
Product Details

The AiM EVO4S is a powerful and flexible data logger and comes equipped with a GPS Module. Offering one connector per channel the EVO4S samples all the information you need, data coming from your vehicle's ECU via CAN, RS232 or K-Line, from the internal accelerometers and gyro and the GPS Module included in the kit.

From analogue/digital inputs, external expansions as well as predefined math channels. Sensors can be connected to 5 configurable analogue channels, to the RPM input and to 2 wheel speed inputs.

Key Features
  • Many options for ECU connection Includes GPS Module
  • Built-in accelerometer & gyro sensor CAN output
  • 5 fully configurable analogue channels 2-speed inputs
Sensors
  • 5 fully configurable analogue channels with configurable 12-bit o-5 Volt, 0-5000 mV inputs or thermocouple input, used to sample data coming from the temperature, pressure, suspension and other sensors.
  • 2-speed inputs which will allow you to monitor different wheel behaviours.
  • Tri-axial accelerometer and gyro is a built-in inertial platform that allows you to understand oversteering, understeering and banking etc.
  • 2 CAN Interface allows you to send messages directly to an existing CAN network to help improve the range of vehicle control possibilities.
  • 4GB memory
  • ECU interface - CAN-Bus, RS232, K-Line and OBDII
  • RPM input manages square wave signals transmitted by the ECU, or pulse signals picked from the coil command (low voltage).
Optional expansion modules
  • Channel Expansion: Permits to add 4 0-5volt analogue channels for pressure, temperature sensors and potentiometers (suspension, steering angle). Two of these channels can be configured to receive digital inputs like wheel speed.
  • TC Hub: Adds up to four "K" type thermocouple temperature sensors.
  • LCU-One Lambda Controller: Wideband Lambda controller LCU-one, with Bosch LSC 4.9 probe provides air/Fuel data, lambda value and exhaust gas temperature.
  • SmartyCam HD/GP HD Cameras: Onboard cameras that overlay onto all your videos all the data sampled by your logger.
Technical
  • ECU Connection: CAN, RS232, K-Line
  • External Modules Connection: GPS Module, Channel Expansion, TC Hub, Lambda Controller, SmartyCam HD
  • Analog Inputs: 5 fully configurable, max 1,000 Hz each
  • Digital Inputs: 2-speed inputs, lap signal, coil RPM input
  • Inertial Platform: Internal 3 axis ±5G accelerometer + 3 axis gyro
  • Digital Outputs: 1 (1 A max)
  • Internal Memory: 4GB
  • Connectors: 13 Binder connectors
  • Body: Anodized Aluminium
  • LEDs: 1 system staus
  • Dimensions: 130 x 35 x 46.6mm
  • Weight: 330g
  • Waterproof: IP65
